BendPak HD7500BLX Garager Boat Lift
SHIPPING PROTECTION ($89)
Protects you from damaged or lost shipments.
Keep your boat stored safely and avoid costly dry-dock fees with the BendPak HD-7500BLX Boat Lift so you can spend more time on the water and less time on repairs
Experience BendPak's Unmatched Boat Protection and safety
Experience unparalleled protection for your watercraft and vehicles with the BendPak HD-7500BLX lift. Engineered to the same strict specifications as BendPak's renowned automotive lifts, this versatile solution offers the perfect blend of boat safety and automotive lifting capabilities.
The HD-7500BLX elevates your precious vessel above the dangers of constant water exposure:
- Shield from salt water corrosion, barnacles, rust, and cold weather damage
- Prevent rub marks, coating blemishes, and wood rot
- Eliminate monthly boat storage fees
- Perfect for both personal use and boat storage businesses
The HD-7500BLX ensures your boat remains high and dry, safe from unpredictable water conditions, floods, and tides that can wreak havoc on in-water lifts.
- Adjustable runways accommodate both boats on trailers and land vehicles
- Wide and narrow installation options fit virtually all boat trailer types
- Doubles as a professional-grade car lift for automotive service
Superior Engineering for Uncompromising Safety
- Four heavy-duty, stainless steel wire ropes, each rated at 14,400 lbs
- Single hydraulic cylinder mounted underneath the runway for durability
- Dual-hub wire rope sheaves reduce stress on axles, sheaves, and cables
- Multiple adjustable height locking positions for variable parking
- Automatic safety locks engage continuously as the lift rises
- Secondary slack-cable device for emergency protection
User-Friendly Features
- Electric-hydraulic power system for ultimate dependability
- Conveniently placed controls for easy operation
- Longer, low-profile approach ramps for effortless trailer loading
- Integrated design protects cables, airlines, safety latches, and sheaves
Built for Longevity and Low Maintenance
- Corrosion-resistant materials withstand harsh marine environments
- Enclosed components extend the lift's lifespan
- Maintenance-free electric hydraulic power system
Perfect for a Variety of use types
- Marine enthusiasts seeking to protect their investments
- Boat storage business owners looking to expand their services
- Auto service centers in coastal areas requiring versatile lifting solutions
Invest in the BendPak HD-7500BLX lift and experience the peace of mind that comes with knowing your boat and vehicles are protected by the best in the industry. Don't leave your precious watercraft vulnerable to water-related damage – choose the superior dry docking solution that also serves as a professional-grade vehicle lift.
Specifications
BendPak HD-7500BLX Specifications
| Capacity | |
|---|---|
| Lifting Capacity* | 7,500 lbs. (3,402 kg) |
| Max Capacity / Front Axle | 3,750 lbs. (1,701 kg) |
| Max Capacity / Rear Axle | 3,750 lbs. (1,701 kg) |
| Rise | |
| A - Min. Runway Height: | 5" (127 mm) |
| B - Max. Rise: | 82" (2,083 mm) |
| C - Max. Lifting Height: | 85.75" (2,178 mm) |
| Time to Full Rise: | 55 seconds |
| Outside Dimensions | |
| D - Overall Width: | 132" (3,353 mm) |
| E - Outside Length: | 198" (5,029 mm) |
| F - Overall Length: | 224.5" (5,702 mm) |
| G - Height of Columns: | 100" (2,540 mm) |
| Inside Dimensions | |
| H - Width Between Columns: | 122" (3,099 mm) |
| I - Drive-Thru Clearance: | 108.5" (2,756 mm) |
| Runways | |
| J - Runway Width: | 19" (483 mm) |
| K - Length of Runways: | 182.25" (4,629 mm) |
| L - Width Between Runways: | 46.5" (1,181 mm) or 66.5" (1,689 mm) |
| M - Runway Centerline: | 68.5" (1,740 mm) or 88.5" (2,248 mm) |
| N - Outside Edge of Runways: | 87.5" (2,223 mm) or 107.5" (2,731 mm) |
| Minimum Wheelbase | |
| Rated Capacity: | 135" (3,429 mm) |
| 75% Capacity: | 115" (2,921 mm) |
| 50% Capacity: | 95" (2,413 mm) |
| 25% Capacity: | 80" (2,032 mm) |
| Locking | |
| Locking Positions: | 17 |
| Lock Spacing: | Every 4" (102 mm) |
| Power Unit | |
| Motor: | 220 VAC / 60 Hz / 1 Ph |
| Noise: | 45 dB |
| Shipping | |
| Weight: | 1,910 lbs. (866 kg) |
| Dimensions: | 191'' x 22'' x 28'' (4,851 mm x 558 mm x 711 mm) |
| Features | |
|
|
| Note: An air supply (minimum: 30 psi / 3 CFM) is required for the safety-lock mechanisms to disengage. It is solely the responsibility of the end-user to provide, install and maintain the air supply. | |
Manuals
BendPak HD 7500BLX Boat Lift Resources
HD-7500BLX Installation And Operation Manual
HD-7500BLX Specifications Sheet
